Andromeda™ DayLite 3-in-1 **DEMO Light**
$645.00 $795.00
Product details
K-A Note: $150 off!! Same Andromeda light you are used to, but this one was used as a demonstrator light on my light board. The wiring pigtails are about an inch shorter than new otherwise it's perfect. (9" of wire pigtail remain) Warranty applies. 14 volt variant. Since it's not technically new, I lowered the price. Sorry, only 1 set available.
MSRP: $795.00 At only 28 millimeters in height (1.102 inch) the new Andromeda™ DayLite is a value light that does not sacrifice anything in performance or standards as other economy-priced lights offered by the competition. Our exclusive and highly advanced optics and chrome reflector system, our unmatched power and LED management circuitry and our famous lowest-drag profile in the industry are all combined into a product that gives you unmatched POWER and FEATURES. Lower, narrower and shorter PLUS much lighter than industry lights in this category!
NOT APPROVED FOR INSTALLATION ON CERTIFIED AIRCRAFT
THIS IS NOT A TSO CERTIFIED LIGHT
| Dimensions (mm): | 134,7 mm x 33,6 mm x 28 mm |
|---|---|
| Dimensions (inches): | 5.303” x 1.325” x 1.102” |
| Weight: | 85 g / 3 oz |
| Operating Voltage Range: | 9 – 18 V DC |
| Input Current – Position / Nav - green (@14V): | 0.43 A |
| Input Current – Position / Nav - red (@14V): | 0.33 A |
| Input Current – Strobe (@14V): | 1.65 A peak |
| Output Power - Position / Nav - green: | 5.2 W |
| Output Power - Position / Nav - red: | 4 W |
| Output Power - Strobe: | 20 W peak |
| Repetition Rate of Strobe: | 50 cycles per minute |
| Recommended size of mounting screw: | M3, stainless steel recommended. Length depends upon placement location on wing tips. |
| Ambient Temperature: | from -40°C to +85°C from -40°F to +185°F |
| Overheat Protection: | Yes |
| Reverse Polarity Protection: | Yes |
| Transient Voltage: | 50 V DC for 1s |
| Under-Voltage Protection: | Yes |
| Over-Voltage Protection: | Yes |
| Waterproof, Dust-proof, Shock-proof, Vibration-proof: | Yes |
For more info, technical specs, drawings, and wiring diagram, click the Installation Manual icon below:
